Trailers
/ Deckover Tilt (FA)
Deckover Tilt (FA)
WIDE LOAD NO FENDERS
15° TILT ANGLE
POWER UP & DOWN LIFT
Deckover Tilt
Arctic Wire Harness
All our wire harnesses are sealed and the front hook up is rated for -65°F.
Pressure Treated Pine Floor
All our lumber is made and installed to withstand weather.
Premium Components
We use brand name quality products for anything we don't produce in house.
3 Year Structural Warranty
All our frames are built tough and we back them up with a 3 year warranty.
Premium Powder Coat
We metal blast and apply a super durable powder coat that will hold up to weather and salt better than liquid.
Full specs & options
14K Sizes & Payload
Size - Weight - Payload
- 102" x 24' - 5,600 lbs - 8,400 lbs
- 102" x 26' - 5,900 lbs - 8,100 lbs
16K Sizes & Payload
Size - Weight - Payload
- 102" x 24' - 5,750 lbs - 10,250 lbs
- 102" x 26' - 6,050 lbs - 9,950 lbs
21K Sizes & Payload
Size - Weight - Payload
- 102" x 26' - 6,525 lbs - 14,475 lbs
Brakes & Suspension
Standard
- Varies by GVWR
- 7K Easy Lube Electric Brake Spring Axles
Options to Exchange or Add On
- 7K Electric Brake Oil Bath Spring Axles
- 7K Easy Lube Electric Brake 22.5° Down Torsion Axles
- 8K Electric Brake Oil Bath Spring Axles
- Triple Axle Configuration (21k GVWR)
Tires
Standard
- Varies by GVWR
- 235/80 R16 (E)10Ply Tire
- Spare Mount
- Spare Tire
Options to Exchange or Add On
- 215/75 R17.5 (H) 16Ply SS Tire Black Wheel
- 235/85 R16 (G) 14Ply Tire With Black Wheel
Frame
Standard
- 16" Spaced Crossmembers
- Treated Yellow Pine Floor
- 10" 12 lb I-Beam Frame
Options to Exchange or Add On
- 12" Spaced Crossmembers
- 11 Gauge Diamond Plate Floor
- Oak Floor
Hitch
Standard
- 2-5/16" 25K Gooseneck Coupler
Options to Exchange or Add On
- 2-5/16" 21K Demco Adjustable Cast Iron Coupler
- 2-5/16" 30K Gooseneck Adjustable Topwind Square Coupler
- 4" Raised Neck & Coupler (ideal for lifted trucks)
- 10" Raised Neck & Coupler (ideal for lifted trucks)
Jack
Standard
- Dual 10K Drop-Leg Jacks
Options to Exchange or Add On
- Dual 10K 2-Speed Jacks
- Dual 10K Hydraulic Jacks
- Dual 25K 2-Speed Jost Jacks
Cargo Loading
Standard
- Rub Rail
- Standard Stake Pockets
- Front Tool Box
Options to Exchange or Add On
- Weld On D-Rings
- Flush Mount D-Rings
- 4' Side Mount Tool Box
- Flush Mount Swivel D-Rings
- 12,500lb Warrior Winch
- Winch Plate
Electrical
Standard
- 3 Way 12V DC Pump
- Led Lights
- Weather Resistant Harness (-65°F)
Options to Exchange or Add On
- Solar Charger
- Wireless Remote Control
Color
Standard
- Lamar Charcoal Gray Powder Coat
Options to Exchange or Add On
- None Available
all product specifications
