Trailers
/ Equipment Tilt Deck Trailer (TD)
Equipment Tilt Deck Trailer (TD)
10,000 lbs PAYLOAD
11° TILT ANGLE
GRAVITY DOWN CUSHIONED CYLINDER
Equipment Tilt Deck Trailer
Arctic Wire Harness
All our wire harnesses are sealed and the front hook up is rated for -65°F.
Pressure Treated Pine Floor
All our lumber is made and installed to withstand weather.
Premium Components
We use brand name quality products for anything we don't produce in house.
3 Year Structural Warranty
All our frames are built tough and we back them up with a 3 year warranty.
Premium Powder Coat
We metal blast and apply a super durable powder coat that will hold up to weather and salt better than liquid.
Full specs & options
14K Sizes & Payload
Size - Weight - Payload
- 83" x 18' - 3,330 lbs - 10,670 lbs
- 83" x 20' - 3,510 lbs - 10,490 lbs
- 83" x 22' - 3,670 lbs - 10,330 lbs
Brakes & Suspension
Standard
- 7K Easy Lube Electric Brake 22.5° Up Torsion Axles
Options to Exchange or Add On
- No Available Options
Tires
Standard
- 235/80 R16 (E)10Ply Tire
Options to Exchange or Add On
- 215/75 R17.5 (H) 16Ply SS Tire Black Wheel
- 235/85 R16 (G) 14Ply Tire With Black Wheel
- Spare Mount
- Spare Tire
Frame
Standard
- 16" Spaced Crossmembers
- 6" Channel Frame
- Treated Yellow Pine Floor
Options to Exchange or Add On
- 8' Deck Over Neck
- 11 Gauge Diamond Plate Floor
- Oak Floor
Hitch
Standard
- 2-5/16" 21K Demco Adjustable Cast Iron Coupler
Options to Exchange or Add On
- 3" 25K Adjustable Pintle Eye Coupler
- 2-5/16" 30K Gooseneck Adjustable Topwind Square Coupler
- 2-5/16" 25K Gooseneck Coupler
- 4" Raised Neck & Coupler (ideal for lifted trucks)
- 10" Raised Neck & Coupler (ideal for lifted trucks)
Jack
Standard
- 10K Drop-Leg Jack
Options to Exchange or Add On
- 10K 2-Speed Jacks
- 10K Hydraulic Jacks
- Dual 10K Drop-Leg Jacks
- Dual 10K 2-Speed Jacks
- Dual 10K Hydraulic Jacks
Cargo Loading
Standard
- Rub Rail
- Standard Stake Pockets
- Six Weld On D-Rings
Options to Exchange or Add On
- Extra Weld On D-Rings
- Extra Stake Pockets
- Flush Mount D-Rings
- Flush Mount Swivel D-Rings
- 12,500lb Warrior Winch
- Winch Plate
- Front Tool Box
- Lockable Chain Rack
- Cable Roller
Electrical
Standard
- Gravity Up & Down Cushioned Cylinder
- Led Lights
- Weather Resistant Harness (-65°F)
Options to Exchange or Add On
- Solar Charger
Color
Standard
- Lamar Charcoal Gray Powder Coat
Options to Exchange or Add On
- None Available
all product specifications
