Extreme Duty Utility Trailer (U6)
13,500lb PAYLOAD
12-26' LENGTHS
6" CHANNEL FRAME
Extreme Duty Utility Trailer
Arctic Wire Harness
All our wire harnesses are sealed and the front hook up is rated for -65°F.
Pressure Treated Pine Floor
All our lumber is made and installed to withstand weather.
Premium Components
We use brand name quality products for anything we don't produce in house.
3 Year Structural Warranty
All our frames are built tough and we back them up with a 3 year warranty.
Premium Powder Coat
We metal blast and apply a super durable powder coat that will hold up to weather and salt better than liquid.
Full specs & options
14K Sizes & Payload
Size - Weight - Payload
- 77" x 12' - 2,436 lbs - 11,564 lbs
- 77" x 14' - 2,436 lbs - 11,564 lbs
- 77" x 16' - 2,550 lbs - 11,450 lbs
- 77" x 18' - 2,736 lbs - 11,264 lbs
- 77" x 20' - 2,940 lbs - 11,060 lbs
- 77" x 22' - 3,036 lbs - 10,964 lbs
- 83" x 12' - 2,436 lbs - 11,564 lbs
- 83" x 14' - 2,440 lbs - 11,560 lbs
- 83" x 16' - 2,550 lbs - 11,450 lbs
- 83" x 18' - 2,730 lbs - 11,270 lbs
- 83" x 20' - 2,935 lbs - 11,065 lbs
- 83" x 22' - 3,036 lbs - 10,964 lbs
- 83" x 24' - 3,150 lbs - 10,850 lbs
- 83" x 26' - 3,250 lbs - 10,750 lbs
16K Sizes & Payload
Size - Weight - Payload
- 83" x 12' - 2,586 lbs - 13,414 lbs
- 83" x 14' - 2,590 lbs - 13,410 lbs
- 83" x 16' - 2,700 lbs - 13,300 lbs
- 83" x 18' - 2,880 lbs - 13,120 lbs
- 83" x 20' - 3,085 lbs - 12,915 lbs
- 83" x 22' - 3,186 lbs - 12,814 lbs
- 83" x 24' - 3,220 lbs - 12,780 lbs
- 83" x 26' - 3,300 lbs - 12,700 lbs
Brakes & Suspension
Standard
- Varies by GVWR
- 7K Easy Lube Electric Brake Spring Axles
Options to Exchange or Add On
- 8K Electric Brake Oil Bath Spring Axles
- 7K Electric Brake Oil Bath Spring Axles
- 7K Easy Lube Electric Brake 22.5° Down Torsion Axles
Tires
Standard
- Varies by GVWR
- 235/80 R16 (E) 10Ply Tire With Black Wheel
Options to Exchange or Add On
- 235/85 R16 (G) 14Ply Tire With Black Wheel
- 215/75 R17.5 (H) 16Ply SS Tire Black Wheel
- Spare Tire Mount
- Spare Tire
Frame
Standard
- Straight Deck
- Wrap Tongue
- 6" Channel Frame
- Diamond Plate Fenders
- Side Rails
- 16" Spaced Crossmembers
- Treated Yellow Pine Floor
- 3" X 2" Angle Toprail (Standard on 12'-20')
- 3" X 3" Tubing Toprail (Standard on 22'+)
Options to Exchange or Add On
- 2' Dove Tail
- 8' Deck Over Neck
- 12" Spaced Crossmembers
- 11 Gauge Diamond Plate Floor
- Oak Floor
Hitch
Standard
- 2-5/16" 21K Demco Adjustable Cast Iron Coupler Bumper pull
Options to Exchange or Add On
- 3" 25K Adjustable Pintle Eye Coupler
- 2-5/16" 25K Gooseneck Coupler
- 2-5/16" 30K Gooseneck Adjustable Topwind Square Coupler
- 4" Raised Neck & Coupler (ideal for lifted trucks)
- 10" Raised Neck & Coupler (ideal for lifted trucks)
Jack
Standard
- Single 10K Drop-Leg Jack
Options to Exchange or Add On
- Dual 10K Drop-Leg Jacks
- Single 10K 2-Speed Jack
- Dual 10K 2-Speed Jacks
- Single 10k Hydraulic Jack
- Pair Of Support Stands
Cargo Loading
Standard
- Standard Stake Pockets
- Side or Rear Slide-In Ramps (dependent on length)
Options to Exchange or Add On
- Front Tool Box
- 5' Spring Assisted Heavy Duty Gate With Ramp Legs
- Weld On D-Rings
- Flush Mount D-Rings
- Flush Mount Swivel D-Rings
- Extra Stake Pockets
- Lockable Chain Rack
- Winch Plate
- 12,500lb Warrior Winch
- Receiver Hitch & Plug
- Pair Of 24" Wide Heavy Duty Stand-Up Ramps
Electrical
Standard
- Led Lights
- Weather Resistant Harness (-65°F)
Options to Exchange or Add On
- Solar Charger
Loading Angles
Standard
- Straight Deck with 57" Slide In Ramps - 25°
Options to Exchange or Add On
- Straight Deck with 5' Gate - 24°
- Straight Deck with 24" Stand Up Ramps - 25°
- 2' Dove with 57" Slide In Ramps - 18°
- 2' Dove with 5' Gate - 17°
- 2' Dove with 24" Stand Up Ramps - 18°
Color
Standard
- Lamar Charcoal Gray Powder Coat
Options to Exchange or Add On
- None Available
all product specifications
