Solid Side Utility
Arctic Wire Harness
All our wire harnesses are sealed and the front hook up is rated for -65°F.
Pressure Treated Pine Floor
All our lumber is made and installed to withstand weather.
Premium Components
We use brand name quality products for anything we don't produce in house.
3 Year Structural Warranty
All our frames are built tough and we back them up with a 3 year warranty.
Premium Powder Coat
We metal blast and apply a super durable powder coat that will hold up to weather and salt better than liquid.
Full specs & options
3K Sizes & Payload
Size - Weight - Payload
- 77" x 12' - 1,520 lbs - 1,980 lbs
- 77" x 14' - 1,630 lbs - 1,870 lbs
- 83" x 12' - 1,565 lbs - 1,935 lbs
- 83" x 14' - 1,720 lbs - 1,780 lbs
5.2K Sizes & Payload
Size - Weight - Payload
- 77" x 12' - 1,545 lbs - 3,655 lbs
- 77" x 14' - 1,655 lbs - 3,545 lbs
- 83" x 12' - 1,585 lbs - 3,615 lbs
- 83" x 14' - 1,740 lbs - 3,460 lbs
7K Sizes & Payload
Size - Weight - Payload
- 77" x 12' - 1,730 lbs - 5,270 lbs
- 77" x 14' - 1,880 lbs - 5,120 lbs
- 77" x 16' - 2,020 lbs - 4,980 lbs
- 3" x 12' - 1,760 lbs - 5,240 lbs
- 83" x 14' - 1,925 lbs - 5,075 lbs
- 83" x 16' - 2,080 lbs - 4,920 lbs
10K Sizes & Payload
Size - Weight - Payload
- 77" x 12' - 1,925 lbs - 8,075 lbs
- 77" x 14' - 2,070 lbs - 7,930 lbs
- 77" x 16' - 2,080 lbs - 7,920 lbs
- 83" x 12' - 1,955 lbs - 8,045 lbs
- 83" x 14' - 2,115 lbs - 7,885 lbs
- 83" x 16' - 2,145 lbs - 7,855 lbs
Brakes & Suspension
Standard
- 5.2K Easy Lube Idler Spring Axle & Electric Brake Spring Axle
Options to Exchange or Add On
- 5.2K Easy Lube Electric Brake Spring Axles
Tires
Standard
- 235/80 R16 (E)10Ply Tire
Options to Exchange or Add On
- Spare Tire Mount
- Spare Tire
Frame
Standard
- 24" Spaced Crossmembers
- Straight Deck
- Smooth Teardrop Fenders
- Treated Yellow Pine Floor
- 4" Channel Frame
- Solid Side Rails with Tarp Hooks
- Wrap Tongue
- 2" X 2" Angle Toprail
Options to Exchange or Add On
- No Options Available
Hitch
Standard
- 2" 7K Ram A-Frame Cast Iron Coupler
Options to Exchange or Add On
- Non Available
Jack
Standard
- 2K Top-Wind Flip Jack
Options to Exchange or Add On
- 7K Drop Leg Jack
Cargo Loading
Standard
- 4' Spring Assisted Lay-Down Gate
- Standard Stake Pockets
Options to Exchange or Add On
- Lockable Fuel Can Rack
- Front Tool Box
- 24" x 24" Tool Cage
- Lockable Trimmer Rack
- Water Cooler Rack
Electrical
Standard
- Led Lights
- Weather Resistant Harness (-65°F)
Options to Exchange or Add On
- None Available
Loading Angles
Standard
- Straight Deck with 4' Gate - 24°
Options to Exchange or Add On
- No Options Available
Color
Standard
- Lamar Charcoal Gray Powder Coat
Options to Exchange or Add On
- None Available
all product specifications
Experience the Lamar Difference: At Lamar, we believe buying and owning a trailer should be simple.
