Trailers
/ Mini Dump
Mini Dump
RIGID RAIL SIDE SUPPORTS
4,500lb - 7,500lb PAYLOAD
ADJUSTABLE COUPLER
SPECS
A TRAILER THAT LASTS
Arctic Wire Harness
All our wire harnesses are sealed and the front hook up is rated for -65°F.
Premium Components
We use brand name quality products for anything we don't produce in house.
3 Year Structural Warranty
All our frames are built tough and we back them up with a 3 year warranty.
Premium Powder Coat
We metal blast and apply a super durable powder coat that will hold up to weather and salt better than liquid.
Full specs & options
7K Sizes & Payload
Axle Quantity - Size - Weight - Payload
- Single Axle - 60" x 10' - 2,220 lbs - 4,780lbs
- Tandem Axle - 60" x 10' - 2,345 lbs - 4,655lbs
10K Sizes & Payload
Size - Weight - Payload
- 60" x 10' - 2,460 lbs - 7,540lbs
Brakes & Suspension
Standard
- Easy Lube Electric Brake Spring Axles Single or Tandem Axle Configuration
Options to Exchange or Add On
- None Available
Tires
Standard
- 235/80 R16 (E)10Ply Tire - Single Axle 7K GVWR
- 205/75 R15 (C) 6Ply Tire - Tandem 7K GVWR
- 225/75 R15 (D) 8Ply Tire - Tandem 10K GVWR
- Spare Tire Mount
Options to Exchange or Add On
- 205/75 R15 (C) 6Ply Tire
- 225/75 R15 (D) 8Ply Tire
- 235/80 R16 (E)10Ply Tire
- Spare Tire
Frame
Standard
- Wrap Tongue
- 4" Channel Frame (25.5" Deck Height)
- Diamond Plate Fenders
- 18" Weld-On Sides (3 cubic yards)
- 16" Spaced Crossmembers
Options to Exchange or Add On
- 24" Solid Metal Side Extensions
- 24" Weld-On Sides (4 cubic yards)
Hitch
Standard
- 2" 10K Demco Adjustable Cast Iron Coupler
Options to Exchange or Add On
- 2-5/16" 21K Demco Adjustable Cast Iron Coupler
Jack
Standard
- 7K Drop-Leg Jack
Options to Exchange or Add On
- Single 10K Drop-Leg Jack
Cargo Loading
Standard
- Front Tool Box
- Barn Doors
- Easy Roll Mesh Tarp
- Standard Stake Pockets
- Pair Of Slide-In Ramps (25°)
Options to Exchange or Add On
- Spreader Gate
- Weld On D-Rings
- Extra Stake Pockets
Electrical
Standard
- Led Lights
- 5 Amp Trickle Charger
- Weather Resistant Harness (-65°F)
- 3.5" X 24" Hydraulic Cylinder (43°)
Options to Exchange or Add On
- Solar Charger
- Wireless Remote Control
Color
Standard
Options to Exchange or Add On
- No Options Available
all product specifications
Experience the Lamar Difference: At Lamar, we believe buying and owning a trailer should be simple.
