Trailers / X-Extreme Duty Deckover

X-Extreme Duty Deckover

12" I-BEAM FRAME
WIDE LOAD NO FENDERS
CARGO TIE DOWNS

X-Extreme Duty Deckover

Arctic Wire Harness
All our wire harnesses are sealed and the front hook up is rated for -65°F.
Pressure Treated Pine Floor
All our lumber is made and installed to withstand weather.
Premium Components
We use brand name quality products for anything we don't produce in house.
3 Year Structural Warranty
All our frames are built tough and we back them up with a 3 year warranty.
Premium Powder Coat
We metal blast and apply a super durable powder coat that will hold up to weather and salt better than liquid.

Full specs & options

30K Tandem Sizes & Payload
Size - Weight - Payload
  • 102" x 25' - 8,890 lbs - 21,110 lbs
  • 102" x 32' - 9,735 lbs - 20,265 lbs
  • 102" x 36' - 10,300 lbs - 19,700 lbs
  • 102" x 40' - 10,840 lbs - 19,160 lbs
30K Triple Axle Sizes & Payload
Size - Weight - Payload
  • 102" x 32' - 9,735 lbs - 20,265 lbs
  • 102" x 36' - 10,300 lbs - 19,700 lbs
  • 102" x 40' - 11,300 lbs - 18,700 lbs
Brakes & Suspension
Standard
  • Varies by GVWR
  • 10K Electric Brake Spring Axles
Options to Exchange or Add On
  • 15K Electric Brake Spring Axles
  • 10K or 15K Electric Brake Hutch Suspension Axles
  • 10K Electric Hydraulic Disk Brake Hutch Suspension Axles
  • 10K Electric Hydraulic Disk Brake Spring Axles
  • 15K Electric Hydraulic Drum Brake Hutch Suspension Axles
  • 15K Electric Hydraulic Drum Brake Spring Axles
Tires
Standard
  • Varies by GVWR
  • 215/75 R17.5 (H) 16 Ply Tire Black Dual Wheel
  • Spare Mount
Options to Exchange or Add On
  • 235/80 R16 (E) 10Ply Tire With Black Dual Wheel
  • 235/75 R17.5 (H) 18Ply SS Tire
  • 235/85 R16 (G) 14Ply Tire With Black Dual Wheel
  • Spare Tire
Frame
Standard
  • Straight Deck
  • Torque Tube (Standard on 36'+)
  • Under-Frame Bridge (Standard on 30'+)
  • 12" 22 lb I-Beam Frame
  • 16" Spaced Crossmembers
  • Treated Yellow Pine Floor
Options to Exchange or Add On
  • 5' Dove Tail
  • 9' Hydraulic Dove Tail
  • 12" 22 lb Low-Profile Pierced-Beam
  • 8' Deck Over Neck
  • 12" Spaced Crossmembers
  • 11 Gauge Diamond Plate Floor
  • Oak Floor
Hitch
Standard
  • 2-5/16" 30K Gooseneck Coupler
  • Ground to Coupler Height - 25" - 33"
Options to Exchange or Add On
  • 3" 35K Adjustable Pintle Eye Coupler
  • 2-5/16" 30K Gooseneck Adjustable Topwind Square Coupler
  • 6" Raised Neck & Coupler (ideal for lifted trucks)
  • 12" Raised Neck & Coupler (ideal for lifted trucks)
Jack
Standard
  • Dual 10K Drop-Leg Jacks
Options to Exchange or Add On
  • Dual 10K 2-Speed Jacks
  • Dual 10K Hydraulic Jacks
  • Dual 25K 2-Speed Jost Jacks
Cargo Loading
Standard
  • Front Tool Box
  • Rub Rail
  • Standard Stake Pockets
  • Pair Of Slide-In Ramps
Options to Exchange or Add On
  • 4' Side Mount Tool Box
  • Weld On D-Rings
  • Flush Mount D-Rings
  • Flush Mount Swivel D-Rings
  • Weld On Strap Winches
  • Sliding Strap Track & Winches
  • Lockable Chain Rack
  • Winch Plate
  • 12,500lb Warrior Winch
  • Receiver Hitch & Plug
  • Pair Of Flip-Over Ramps
  • Pair Of Rhino Ramps
Electrical
Standard
  • Led Lights
  • Pair Of Side Turn Flashers (Standard on 30'+)
  • Weather Resistant Harness (-65°F)
Options to Exchange or Add On
  • Solar Charger
Loading Angles
Standard
  • Straight Deck with 96" Slide In Ramps - 22°
Options to Exchange or Add On
  • 5' Dove with Rhino Ramps - 18°
  • 9' Dove with Hydraulic Dove - 20°
Color
Standard
  • Lamar Charcoal Gray Powder Coat
Options to Exchange or Add On
  • None Available

all product specifications
